Part# 19
Cast Double Arm Pull
Specify door thickness if other than 1-3/4"
| Centers | -- |
|---|---|
| Overall | 8-3/4" |
| Clearance | -- |
| Projection | 3-1/4" |
| Base | 1-1/2" × 1-5/8" |
| Finishes |
US3/605 – Bright Brass US4/606 – Satin Brass US5/609 – Antique Brass US10/612 – Satin Bronze US10NL - Satin Bronze NO LACQUER US10B/613 – Dark Bronze Oxidized US26D/626 – Satin Chrome Plated*** Flat Black Powder Coat Dark Bronze Powder Coat |
| Standard Fasteners |
Type 1 -1/4-20 X 2-1/4 Thru Bolt & Finish Washer (1-3/4" door) ***US 26D - 4 - #8 SMS Surface mounted |
| Mounting Options | Security Fastener 1/4-20 × 2-1/2" Machine Screw |
| ANSI | J401 |
